High reputation Biobase China Nitrogen&Hydrogen&Air Generator

Technical parameters:

N2 Capacity: 5 ~ 3000Nm3/h

N2 Purity: 95% ~ 99.999%

N2 Pressure: 0.1 ~ 0.8 MPa(Adjustable)

Dew point:-40ºC or -60ºC

Feature:

1. The operation is simple, the performance is stable, the automation level is high, and it can be realized without operation.

2. Reasonable internal components, uniform air distribution, and reduce the high speed impact of airflow.

Send email to us

Product Detail

Product Tags

We have been committed to offering easy,time-saving and money-saving one-stop purchasing provider of consumer for High reputation Biobase China Nitrogen&Hydrogen&Air Generator, To gain from our strong OEM/ODM capabilities and considerate products and services, make sure you contact us today. We’re going to sincerely develop and share achievement with all clients.
We have been committed to offering easy,time-saving and money-saving one-stop purchasing provider of consumer for China 10L Oxygen Generator, Medical Oxygen Generator, During the short years, we serve our clients honestly as Quality First, Integrity Prime, Delivery Timely, which has earned us an outstanding reputation and an impressive client care portfolio. Looking forward to working with you Now!

Product Video

Process

Technical characteristics

1. Special carbon molecular sieve protection measures to extend the life of carbon molecular sieve.
2. The key components of famous brands are the effective guarantee of equipment quality.
3. The automatic emptying device of national patent technology guarantees the nitrogen quality of finished products.
4. It has many functions of fault diagnosis, alarm and automatic processing.
5. Optional touch screen display, dew point detection, energy saving control, DCS communication and so on.

Specification

Model	N2 capacity Nm3/h	Effective air consumption Nm3/min	Air purification system	Inlet and outlet diameter		structure
SPN-5	5	0.24	KJ-0.5	DN15	DN15	A
SPN-10	10	0.47	KJ-0.5	DN15	DN15
SPN-20	20	0.94	KJ-1	DN25	DN25
SPN-60	60	2.82	KJ-3	DN32	DN40	B
SPN-100	100	4.7	KJ-6	DN40	DN40
SPN-200	200	9.4	KJ-10	DN50	DN50
SPN-400	400	18.8	KJ-20	DN65	DN50
SPN-800	800	37.6	KJ-40	DN100	DN65
SPN-1200	1200	56.4	KJ-60	DN125	DN80	C
SPN-1500	1500	70.5	KJ-80	DN150	DN80
SPN-2000	2000	94.0	KJ-100	DN150	DN80
SPN-2500	25000	117.5	KJ-120	DN150	DN100
